Kingbull Voyager | Dual-battery Cargo Electric Bike Range Up to 100 Miles

Name: Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike
Brand: KINGBULL
SKU: KDVG-ORANGE
Price: 1399.0 USD
Availability: OutOfStock

Geared Hub Motor 750W

Lithium Ion Battery 2*17.5Ah

Range Up To 100 Miles

Top Speed 28 MPH

Payload Capacity 440lb

CST Tires 20"X4.0"

2-Year Warranty Cover all bike purchases

Pass Test Pass the test with UL 2849

$2,299.00 $1,399.00

Shipping: Within 2 Business Days

SAVE$900.00

CA shipping, delivered in 3 to 7 business days

Color

Grey

Orange

Style

Dual Battery Ebike

Quantity

Free Shipping

15-Day Returns

Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike

Compatible Accessories

Sold Out

Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike

$2,299.00 $1,399.00

Compatible Accessories

Sold Out

Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike

$2,299.00 $1,399.00

Size & Fit

A —— Total Length 69in

B —— Total Height 48in

C —— Wheelbase 48in

D —— Minimum Seat Height 33in

E —— Maximum Seat Height 41in

F —— Chain Stay Length 20in

G —— Down Tube Length 22in

H —— Top Tube Length 22in

I —— Wheel Diameter 22in

J —— Head Tube Length 7.9in

K —— Handlebar Length 11in

L —— Rear Rack Height 29.5in

Technical Specifications

Model: Kingbull Voyager

Motor: 750W (Sustained), 48V Brushless Rear Hub Motor

Throttle: Thumb Throttle

Display: LCD Colorful screen with USB

Top Speed: 28 MPH

Range: Up to 100 miles

Battery: 2*Removable Lithium-ion 48V, 17.5Ah Battery

Charger: 48V 3A Charger

Sensor: Speed

Pedal Assist: 5 Levels

Pedals: 9/16" All Aluminum Alloy

Fork: Aluminum 20'' Suspension Hydraulic Front Fork

Frame: 6061 Aluminum Alloy with Internal Battery

Tires: Reflective stripe, CST, custom 20" x 4.0" Fat Tires

Crankset: 170mm w/ 48T

Rear Derailleur: Shimano 7 speed

Brakes: Hydraulic

Chain: 124Link

Seat Post: Aluminum alloy, dimensions of Ø33.9*350mm, equipped with a clamp and scale.

Handlebars: Aluminum 31.8mm, 700mm

Weight: 86.6lbs

Payload Capacity: 440lbs

Rear Rack Weight Limit: 180lbs

Frame Style: Step-Through

Recommended Height: 5'1" - 6'5"

Technical Overview

DualPower Cargo E-bike Voyager, a robust and efficient transportation solution. Powered by a powerful 750W motor and equipped with two high-capacity 17.5Ah batteries, this bike offers incredible performance. With its sturdy frame, it can handle a substantial payload of 440 pounds. With a top speed of 28 miles per hour and an impressive range of 100 miles, the DualPower Cargo E-bike Voyager is perfect for long rides. What sets it apart is the ability to simultaneously use both batteries, ensuring a prolonged and uninterrupted journey. Whether you are exploring the city or transporting goods, this e-bike is your reliable partner.Say goodbye to range anxiety and embrace the freedom of extended rides with this exceptional e-bike.

Geared Hub Motor 750W

Lithium Ion Battery 2*17.5Ah

Range Up To 100 Miles

Top Speed 28 MPH

Payload Capacity 440lb

CST Tires 20"X4.0"

2-Year Warranty Cover all bike purchases

Pass Test Pass the test with UL 2849

[{"id":47551939903770,"title":"Grey \/ Dual Battery Ebike","option1":"Grey","option2":"Dual Battery Ebike","option3":null,"sku":"KDVG-GRAY","requires_shipping":true,"taxable":false,"featured_image":{"id":46618648084762,"product_id":8898240119066,"position":2,"created_at":"2024-06-26T23:29:47-07:00","updated_at":"2024-06-26T23:29:48-07:00","alt":null,"width":2000,"height":2000,"src":"\/\/www.kingbullbike.com\/cdn\/shop\/files\/CARGO-6-27-2000x2000-v4.webp?v=1719469788","variant_ids":[47551939903770]},"available":false,"name":"Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike - Grey \/ Dual Battery Ebike","public_title":"Grey \/ Dual Battery Ebike","options":["Grey","Dual Battery Ebike"],"price":139900,"weight":0,"compare_at_price":229900,"inventory_management":"shopify","barcode":"719704781190","featured_media":{"alt":null,"id":39129465225498,"position":2,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/www.kingbullbike.com\/cdn\/shop\/files\/CARGO-6-27-2000x2000-v4.webp?v=1719469788"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":47551939838234,"title":"Orange \/ Dual Battery Ebike","option1":"Orange","option2":"Dual Battery Ebike","option3":null,"sku":"KDVG-ORANGE","requires_shipping":true,"taxable":false,"featured_image":{"id":46618647953690,"product_id":8898240119066,"position":1,"created_at":"2024-06-26T23:28:07-07:00","updated_at":"2024-06-26T23:28:08-07:00","alt":null,"width":2000,"height":2000,"src":"\/\/www.kingbullbike.com\/cdn\/shop\/files\/CARGO-6-27-2000x2000-v9.webp?v=1719469688","variant_ids":[47551939838234]},"available":false,"name":"Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike - Orange \/ Dual Battery Ebike","public_title":"Orange \/ Dual Battery Ebike","options":["Orange","Dual Battery Ebike"],"price":139900,"weight":0,"compare_at_price":229900,"inventory_management":"shopify","barcode":"719704781183","featured_media":{"alt":null,"id":39129364922650,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/www.kingbullbike.com\/cdn\/shop\/files\/CARGO-6-27-2000x2000-v9.webp?v=1719469688"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

{"id":47551939838234,"title":"Orange \/ Dual Battery Ebike","option1":"Orange","option2":"Dual Battery Ebike","option3":null,"sku":"KDVG-ORANGE","requires_shipping":true,"taxable":false,"featured_image":{"id":46618647953690,"product_id":8898240119066,"position":1,"created_at":"2024-06-26T23:28:07-07:00","updated_at":"2024-06-26T23:28:08-07:00","alt":null,"width":2000,"height":2000,"src":"\/\/www.kingbullbike.com\/cdn\/shop\/files\/CARGO-6-27-2000x2000-v9.webp?v=1719469688","variant_ids":[47551939838234]},"available":false,"name":"Kingbull Voyager(Dual Battery) | Long Range Step Thru Electric Bike - Orange \/ Dual Battery Ebike","public_title":"Orange \/ Dual Battery Ebike","options":["Orange","Dual Battery Ebike"],"price":139900,"weight":0,"compare_at_price":229900,"inventory_management":"shopify","barcode":"719704781183","featured_media":{"alt":null,"id":39129364922650,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/www.kingbullbike.com\/cdn\/shop\/files\/CARGO-6-27-2000x2000-v9.webp?v=1719469688"}},"requires_selling_plan":false,"selling_plan_allocations":[]}

Media Reviews

Dual Battery

Double batteries, ideal for long rides and heavy cargo. Experience a more robust and reliable journey with Kingbull Voyager.

Shimano Gear Transitions

Our 7- speed derailleur is engineered to provide effortless andseamless gear transitions. Say goodbye to chain drops andfrustrating shifts.

Front Suspension

A front suspension fork with up to 80mm of travel means you can ride anywhere and everywhere with comfort and confidence!

Integrated Lights & Turn Signal

Featuring brake lights and an integrated taillight, the lights signal turns and brakes, ensuring safe riding day or night with the Kingbull Voyager.

Hydraulic Brakes

Our state-of-the-art hydraulic braking system provides excellent braking power to ensure a safe and smooth ride, even in hard braking situations.

Backlit LCD Display With USB Charging

Monitor your speed, battery life, distance traveled, pedal assist level, and much more with the intuitive Color Display.

Pedal Assist & Throttle

Throttle on demand and 5 levels of pedal assist will maximize your efforts and minimize the amount of energy you use.

Dropper Seatpost

By squeezing the lever beneath the seat, you can easily glide the seat up or down to feel comfort over your riding position.

Our Design Advantages

The uni-body frame and one-piece wheel structure make the bike more stable and much more load capacity.

Ultra-long Range

Voyager excels in durability and performance. The dual-battery version, featuring two powerful 17.5Ah lithium batteries, doubles the range for a carefree 100-mile journey on a single charge. This unmatched range experience offers cyclists unprecedented convenience.

Sturdy and Durable

The Kingbull Voyager features an upgraded 6061 aluminum alloy integrated frame, ensuring a sturdy and durable build.With a maximum load capacity of 440 pounds and a rear cargo capacity of 180 pounds,it is well-suited for carrying everything from adventure gear to household items.

6061

Aluminum Alloy

440 lbs

Payload

Powerful Motor

The Voyager's motor uses an updated 750W Upgraded Brushless Geared Hub Motor and specialized inner ring, which enables high-temperature resistance and better heat dissipation. This inner ring reduces the motor magnets' attenuation speed, which guarantees longer life expectancy for the motor, meaning your Kingbull Voyager will outlast the competition where it matters most—the power system.

750W

Motor Power

80Nm

Max Motor Torque

Integrated Battery Design

Built-in 840Wh high-capacity lithium battery in the frame, with a maximum range of more than 60 miles. Aluminum alloy battery box, better heat dissipation, built-in battery design, safer, more durable, more waterproof, more beautiful.

17.5Ah

Lithium Battery

840Wh

Larger Capacity

60 Miles

Range Up To

High-quality Fat Tires

Newly upgraded one-piece wheels are like vehicle wheels, stronger than spoked wheels, and the 4-inch puncture-proof fat tires make it easy to ride on city roads, in the snow, and at the beach.

Get On/Off Easily

The step-through frame offers riders of different ages and abilities a more convenient, comfortable, and enjoyable cycling experience.

Alloy Pedals

Spacious and larger pedal surface crafted for optimal foot support, enhancing the riding experience with improved stability, water-resistant and corrosion-resistant, easier to maintain.

Color LCD Display

Backlight display provides the information of speed, mileage, power, etc.

Battery Capacity

A fuel gauge for your electrons.

Odometer

Calculate how many miles you have ridden.

Pedal Assist Level

Pedal assistance power adjustment.

Speedometer

Can be set to current speed, max speed, or average speed.

USB Charging

It can charge your dying cell phone.

Wattmeter

Displays motor power output in real-time.

Versatile Design

Voyager, with its versatile design and wide range of accessories, meets all your transportation needs. Whether carrying cargo or enjoying a pleasant ride with loved ones, it enhances your cycling experience by providing the right gear for every occasion.

What’s in the Box

Body Assembly

CTS Tires

Battery &Charger

Pedal

LCD Display

Headlight

Rearview Mirror

Bungee Cord

Rear Footrest Pegs

Rear Rack Wooden Cushion

Product Manuals

Inflator

Repair Tool Kit

Manuals & Videos

Assembly video

Resource Articles

Riding videos

Distance Range

Geometry &Sizing

Your Fully Loaded Multifaceted Cargo Ebike

New Bike, New Questions

It's 400lbs with 180lbs for rear rack.

The bike comes 85% assembled.

Just like the single battery version, keep all batteries stay in the bike for charging.

You can check our Compare Models in the menu for the differential of our Ebike.

Strongly recommend you read our E-BIKE USER MANUAL for your safety.

No, you don’t need a license for riding Ebike.

Haven't received saddlebags water bottle or cover.

Still haven't received the saddlebags Or? the cover for the bicycle and the water bottle.

Thank you for your feedback. All of your accessories are in transit and you can check them with the tracking number in your order. We will also urge the logistics and transportation company to deliver it to you as soon as possible. Thank you for your support and understanding!

Voyager Dual Battery

We love our bikes. They are very well designed and look great! The assembly was pretty easy and customer service response is excellent. My only suggestion would be to include the Dual battery wiring instructions with the assembly instructions... Overall, these are nice bikes with extended range.

Thank you for your support and affirmation. We will consider your suggestions and continue to improve the instructions.

Electric Bicycle

I saw your ad and am interested in learning more. Please contact me.

Great bike!

I bought a dual-battery of the bicycle, as well as a front basket and a rear basket. The front and rear baskets are shipped separately from the ebike. The quality of the basket is much better than I expected. It looks like it is welded. The bike is solid, has a very nice build quality, and is better quality and cheaper than some of our local bike shops. If they sell such an electric bicycle in our local area, it will cost at least $2,500 or more. So far, so good.

Really good I'm satisfied with the purchase.

This ebike is perfectly made, great design and suspension. It's a little heavy, but I think it's ok.
I like the dual battery option, I want to be able to ride consistently so I can go far away without worrying about power.
I've been using both batteries at the same time which reduces how often I have to charge them, right now I ride every day but I only need to charge both batteries almost once every two weeks.
I definitely recommend it.
